Body Material: 4140
O-ring Material: Viton-70 Durometer
| Item | Description | ||
|---|---|---|---|
| Type | 2-3/8in (60.3mm) | 2-7/8in (73.0mm) | |
| Part No. | RCPVD01238000 | RCPVD01288000 | |
| O.D. Max | 77.8mm | 93.17mm | |
| I.D | 30mm | 40mm | |
| Make-up Length/Overall Length | 475mm | 498mm | |
| Connection | Upper Thread | 2-3/8 EU BOX | 2-7/8 EU BOX |
| Bottom Thread | 2-3/8 EU PIN | 2-7/8 EU PIN | |
| Vent Area | 706.86 mm² | 1810mm² | |
| Break Value of One Shear Pin | Theoretical Value：2.48MPa Reality Value：See《Shear Pin Specification Sheet》 | Theoretical Value：2.06MPa Reality Value：See《Shear Pin Specification Sheet》 |
|
| Minimum pressure of vent | 4.96MPa | 4.12MPa | |
| Max Temp | 200℃ | ||
| Pressure Rating | 120 MPa | ||
| Tensile | P110 | ||
