Body Material: 4140
O-ring Material: Viton-70 Durometer
Disk Material: Ceramic
| Item | Description | |
|---|---|---|
| TYPE | 2-3/8in(60.3mm) | 2-7/8in（73.0mm） |
| Part No. | RCBDS01238000 | RCBDS01288000 |
| Max Pressure | 10000PSI (70MPa) | 10000PSI (70MPa) |
| O.D. MAX | 3.062in (77.8mm) | 3.669in (93.2mm) |
| I.D. | 1.995in (50.6mm) | 2.36in (60mm) |
| Overall Length | 18.86in (479mm) | 20in (508mm) |
| Connection | 2-3/8 EU (B×P) | 2-7/8 EU (B×P) |
| Tensile | 135000lb （60048daN） | 198000lb （88070daN） |
| Max Temp | 392°F(200°C) |
