Technical Information

Sub O.D.	Thread Type*(upper/bottom)	Pressure Rating
2 in	1 11/16–8 STUB ACME–2G	25000 psi[172Mpa]
2 7/8in	2 3/8in –6Acme–2G	25000 psi[172Mpa]
3 1/8in	2 3/4in –6Acme–2G	25000 psi[172Mpa]
3 3/8in	2 13/16in –6Acme–2G	25000 psi[172Mpa]
4 1/2in	3 15/16in –6Acme–2G	25000 psi[172Mpa]
7 in	6 1/4in –6Acme–2G	25000 psi[172Mpa]

**All weights are theoretical

Selection Chart

Sub O.D.	Part No.	0-ring Size
2 in	RMB2TS11116000	AS−2213.53x φ 36.09
2 7/8in	RMB2TS23800000	AS−2273.53x φ 53.57
3 1/8in	RMB2TS23400000	AS−2303.53x φ 63.10
3 3/8in	RMB2TS21316000	AS−2313.53x φ 66.30
4 1/2in	RMB2TS31516000	AS−3425.33x φ 91.45
7 in	RMB2TS61400000	AS−3615.33x φ 151.75

Regular monitoring, inspection, and maintenance of products are mandatory per RME guidelines to ensure optimal performance. Non-compliance may lead to personal injury or property damage. For inquiries, contact your designated RME representative.
