Gun Body Material: Heat treated, seamless steel tubing
Gun Body Configuration: Threaded and Scalloped
Charge Tube Type: Round steel tube
Type of Tandem Connection: Booster-to-booster
Initiation Point: Top or bottom fired options available for wireline and TCP
O-Ring Material: Nitrile-90 Durometer or Viton-95 Durometer
O-Ring Size for Threaded Gun: AS361-NBR-90-1 / A2361-FKM-95-1
Spacer Gun Kit: 178-D-SK-1
Booster Kit: BK-D-1
*Customization Acceptable*
| Specifications | |
|---|---|
| Phasing | 135° |
| Nominal O.D. | 7in [177.8mm] |
| Nominal Thickness | 0.5 in [12.7mm] |
| Drift Dia. | 5.94 in [150.876mm] |
| Pressure Rating | 13000 psi [89.6MPa] |
| Gun End to First Scallop Distance | 6.5in [165.1mm] |
| Gun Swell at Liquid | 7.2in [183mm] |
| Max Tension | 952,000lbf [4,233kN] |
| Thread | 6 1/4"-5Acme |
| Charge Info | 25gDP3 |
| Assembly Part No. | Carrier Part No, | Length | Shot Total | Assembly Weight |
|---|---|---|---|---|
| 178-12-135-04-25gDP3-GA-D | 178-12-135-04-25gDP3-G-D | 4ft | 36 | 164lb (74.4kg) |
| 178-12-135-07-25gDP3-GA-D | 178-12-135-07-25gDP3-G-D | 7ft | 72 | 286.6lb (130kg) |
| 178-12-135-11-25gDP3-GA-D | 178-12-135-11-25gDP3-G-D | 11ft | 120 | 450.8lb (204.5kg) |
| 178-12-135-14-25gDP3-GA-D | 178-12-135-14-25gDP3-G-D | 14ft | 156 | 573.9lb (260.3kg) |
| 178-12-135-21-25gDP3-GA-D | 178-12-135-21-25gDP3-G-D | 21ft | 240 | 860.7lb (390.4kg) |
