Gun Body Material: Heat treated, seamless steel tubing
Gun Body Configuration: Threaded and Scalloped
Charge Tube Type: Round steel tube
Type of Tandem Connection: Booster-to-booster
Initiation Point: Top or bottom fired options available for wireline and TCP
O-Ring Material: Nitrile-90 Durometer or Viton-95 Durometer
O-Ring Size for Threaded Gun: AS346-NBR-90-1 / A2346-FKM-95-1
Spacer Gun Kit: 127-D-SK-1
Booster Kit: BK-D-1
*Customization Acceptable*
| Specifications | |
|---|---|
| Phasing | 60° |
| Nominal O.D. | 5in [127mm] |
| Nominal Thickness | 0.415 in [10.5mm] |
| Drift Dia. | 4.17 in [106mm] |
| Pressure Rating | 9500 psi [70MPa] |
| Gun End to First Scallop Distance | 7.2in [182.8mm] |
| Gun Swell at Liquid | 5.19in [132mm] |
| Max Tension | 219,100lbf [975kN] |
| Thread | 4.5"-6Acme-2G |
| Charge Info | 26g GH |
| Assembly Part No. | Carrier Part No, | Length | Shot Total | Assembly Weight |
|---|---|---|---|---|
| 127-8-60-04-26gGH-GA-D | 127-8-60-04-26gGH-G-D | 4ft | 27 | 121.2lb (54.9kg) |
| 127-8-60-07-26gGH-GA-D | 127-8-60-07-26gGH-G-D | 7ft | 53 | 212.1lb (96.1kg) |
| 127-8-60-11-26gGH-GA-D | 127-8-60-11-26gGH-G-D | 11ft | 79 | 333.3lb (151.9kg) |
| 127-8-60-14-26gGH-GA-D | 127-8-60-14-26gGH-G-D | 14ft | 105 | 424.2lb (192.1kg) |
| 127-8-60-21-26gGH-GA-D | 127-8-60-21-26gGH-G-D | 21ft | 157 | 636.3lb (288.5kg) |
